Schematic Diagram of Reactor
Is located in Rogers Hall room 114. Sectors in schematic represent shelves in the above photo, with sector 1 being top left. Note the middle top and bottom shelves were combined into sector 3 in the schematic. Schematic design by Charlie Knust.
Reactor Guide
Here is a picture of the completed reactor located in Rogers Hall Room 114 (Queens University of Charlotte). Sectors 1-5 are delineated in white.
Parts List
The following items were purchased from local vendors (whenever possible) and used to construct the 20L reactor shown above:
Reactor Item
Number of Units
Price Per Unit
Sector Number*
Blue Number**
1/2″X260 PYFE THRD SEAL TAPE GAS
1
$3.85
1, 2, 3, 4
NUTS , BOLTS, FASTENERS
18
$5.59
1, 2, 3, 4, 5
8LB OIL DRI OIL ABSORBENT
6
25.99
1, 2, 3, 4
Total
240
$3,054.70***
*Above in schematic, **If applicable, ***Does not include tax
Item
Price
# of Units
Total
$3,002.23
